At Circle W, our double axle dump trailers are equipped with a straight ram hydraulic lifting system that lifts the trailer bed from the frame. Standard features include a lockable pump box, d-rings inside the box, barn door rear gate, LED lights, Interstate deep cycle battery, drop leg jack, 2” A-Frame Coupler, and safety chains. The dump body is powder coated with 20“-24” high sides and features a smooth steel floor. 6,000#, 7000#, or 10,000# axle upgrades are also available. In addition to our standard bumper-pull trailers, we also manufacture gooseneck dump trailers.
- SANDBLASTED / POWDER COAT / PAINTED BLACK
- 2 5/16" ADJUSTABLE COUPLER
- TONGUE: 8" X 10" I-BEAM
- BREAKAWAY KIT
- SAFETY CHAINS
- SIDE HEIGHT: 20" - 12 ga STEEL WALLS
- RAMPS: 6' SLIDE IN
- PUMP: KTI 12V HYDRAULIC PUMP
- CYLINDER: 5" X 16"
- REFLECTIVE TAPE
- AXLES: (2) 7000# AXLES W/ELECT BRAKES
- WIRING: ALL WEATHER HARNESS
- JACK: (1) 10,000# DROPLEG
- TONGUE LENGTH: 59"
- (4) D RINGS WELDED INSIDE CORNERS
- SPARE TIRE MOUNT ONLY
- FLOORING: 10 ga STEEL
- MAIN FRAME: 10ga | BEAM
- TILT ANGLE: 45"
- GATE: BARN DOOR / SPREAD
- LIFT SYSTEM: HYDRAULIC - POWER UP/DOWN /GRAVITY
- SCISSOR: HEAVY DUTY SCISSOR LIFT
- TARP KIT: PULL BAR 7' X 20'
- TIRES: (4) ST23580R16 10 PLY BLACK SPOKE WHEELS
- LIGHTS: DOT APPROVED LED LIGHTS
6′ x 10′
G.V.W.R: 9,990#
Axles: 2 x 5,200#
Trailer Weight: 2,750#
Trailer Payload: 7,240#
6′ x 12′
G.V.W.R: 9,990#
Axles: 2 x 5,200#
Trailer Weight: 2,930#
Trailer Payload: 7,060#
7′ x 12′
G.V.W.R: 14,000#
Axles: 2 x 7,000#
Trailer Weight: 3,570#
Trailer Payload: 10,430#
7′ x 14′
G.V.W.R: 14,000#
Axles: 2 x 7,000#
Trailer Weight: 3,960#
Trailer Payload: 10,040#
7′ x 16′
G.V.W.R: 14,000#
Axles: 2 x 7,000#
Trailer Weight: 4,250#
Trailer Payload: 9,750#
